TAKAYA9401
TAKAYA9401 Fly飞针测试仪-Takaya APT-9401SL


FPTltemsDescriptionInformation
CompuController configurationPC brandHp
PC nameAPT-9401SL
FC Coeration System,mark packiP1.P4Win XP Pack3
Tester hard wareTester configurationTAKAYA softare versionAPT-940-SL    4.1-7
SeriesAPT-9401SL
Tester option informationInput Voltage iV
     Input Current (A)
220V
     10A
Inout Power (KVAIKWh2.2KW
Made in Place (country name
     Manufacturing Date
Japan
     NOV.2009
 SpecificationSpecification of testable PCB
     Test
Maximum Size L"W660mmx635mm(26"x25
Minimum Size L-W50x50mm
Thickness0.8-4.0mm
TOP side component space35mm
Bottom side component space90mm
Weight3.0    Ka or less
non-mountable area at fron side3    mm top and Bot
non-mountable area at rear side
     combination test methoc
3    mm top and Bot
     0.03-0.05sec/step
Speedsinale    test method0.08-0.10    secisten
measuring
     Probes
unside4    movind
underside2    adiustable
sensor
     Probes
upside2    moving
underside6    adjustable
motor
     type
XaxisAC    servo motor
Y axisAC    son moto
Z axisStepping    servo -high speed and high torque
Position resolutionXaxis2    5um
Y axis2.5um
Z axis50um
Position repeatabilityX    axissoum
Y axis50um
ZaxisNIA
minimum probe contact pitch0.18mm    aporox
minimum probe contact pad size150um    approx
Probe tip type with high precisiorSmall    4-crown or Needle
Probe mounting angleProbe    1X-12°Y-50
Probe 2X-4”Y+50
Probe 3X+4°Y-5”
Probe 4X+12°Y+50
intermal measurement sourcesDC    constant voltage 10.2V
DC constant voltage 20.1-25V(Programmable.max0.5A    to 1Ai
DC constant cuttent 1500nA-50mAiLimit    voltage:0.01-2.5v
DC constant cuttent 250uA-20mA(Limit    voltage:0.5-5v)
AC constant voltage70mVrms(f-160Hz,1.6kHz,16kHz,160kHz

measuring rangesLow value resistance40 mOHM-400QHMi4-wire kelvin method
resistors0.4ohm-40Mohm
capacitors4pF-40mF
Inductor4uH-400H
Impedance
     Diodes/transistor junctions
33ohm-330Kohm
     0.1V-2.5V
Zener diodes0.4V-40V
DC voltage
     AC voltage
0.04V-25mvs
DC current0.1A-1A
short or open1    ohm-400 ohm
transistor/FET/Phone couplesOn    chark
RelavsOn    check
IC ead open test in bus circuitOpen    check
Test stepsMax    300 000 steps
Guarding pointsmax    4 points / step
Judgment tolarance sel0-+999%/-99%,more/less    than reference
     value or absolute value
